FUNCTION DISPLAY

Double sided brush+bottom suction cup

High pressure washing

Barrier crossing high-pressure cleaning

Tail handheld straw
PRODUCT VIDEO

Without Manual Focusing

Without Mauual Focusing

Without Mauual Focusing
Technical Paramenters
Items | Units | Spec. |
---|---|---|
Vehicle type | JBY5040TYHT5001 (4.5T chassis) | |
Cab | Single row cab | |
Number of passengers | 3 | |
Rated/Peak power | kW | 55/110 |
Rated/Peak torque | Nm | 150/318 |
Rated/Peak speed | rpm | 3500/12000 |
Cooling mode | Water-cooling | |
Number of sweeps | 2 | |
Brush diameter | mm | 800 |
Effective cleaning width | mm | 2200 |
Cleaning area | ㎡/h | 30000 |

Click the download button,you can get all machine parameters

Chassis Section
– Load-bearing chassis
– Rigid cold riveted frame
– Specialized load-bearing asymmetrical suspension system
– Radial car tires

Battery Section
-100% battery-powered 72V/600AH-800AHlithium battery
– 80-100 km working range
– 2-hour fast charging

Large-Capacity Garbage Bin
Equipped with a 3 cubic meter garbage bin and a 1.2 cubic meter clean water tank, along with a dust filtration system. It features large storage capacity and dust-free operation.

Control Screen
– High-definition LCD dashboard for convenient operation
– Spacious driver’s cabin
– Smooth, stable, and quick driving

Efficient and Durable Road Sweeping Brush
Powerful Bristles, Flexible Sweeping, Long-Lasting Durability, Eco-Friendly and Efficient

VEHICLE ADVANTAGES
One-Touch Operation
A one-touch control panel with integrated functions for convenient and easy operation..

LED Lights
These high-brightness LED indicator lights offer long-range visibility, ensuring road safety in all weather conditions. Their low power consumption and long lifespan not only reduce maintenance costs but also enhance the overall efficiency of the vehicle, providing operators with a safer and more convenient experience.

Multiple working modes
15m hose reel at the rear for cleaning across obstacles,
Handheld High Pressure Gun Cleans Across Obstacles.
